Machine Tool Loading and Unloading Integrated Production Line
- Based on the loading and unloading workstation of machine tools, it integrates vertical warehouse, AGV, cleaning machine, camera and other equipment to realize the automation and unmanned operation of the whole process.
- It can be used for the processing of complex parts.
- Industrial robots are equipped with quick-change fixtures to achieve maximum flexibility.
- The workpieces are transported in the form of pallets to achieve diversified processing of workpieces.
| Serial number | Item | Technical Parameters |
| 1 | Number of warehouse positions | 130 |
| 2 | AGV | Laser + QR code navigation |
| 3 | Processing equipment | Machine tools, laser engraving machines |
| 4 | Testing equipment | 3D camera |
| 5 | Cleaning equipment | Ultrasonic cleaning machine |
| 6 | Robot motion range (mm) | 1800 |
| 7 | Robot load (kg) | 20 |
| 8 | Number of fixtures | 3 |
| 9 | Pallet size (mm) | 400*300 |
| 10 | Control system | PLC |
| 11 | Upper software | WMS/MES |
Options
- Expandable process equipment.
- Customizable pallets.
- Customizable robot fixtures.
- Customizable upper software.
Main configuration
| Serial number | Name | Specification/Description |
| 1 | Stereoscopic | warehouse Stacker automatically picks and places materials, 130 positions |
| 2 | Industrial robot | 6 axis, motion range 1800mm |
| 3 | AGV | SLAM laser navigation |
| 4 | Machine tool | High-speed five-axis |
| 5 | Cleaning machine | Ultrasonic cleaning |
| 6 | Control system | PLC module, connecting robots, silos, safety systems, etc. |
| 7 | Upper software | Human-machine interaction interface, operating basic equipment operation, monitoring equipment working status |
